Ev Charger Type 1 To Type 2 Model 3 Cable J1772 To 62196

Name: Ev Charger Type 1 To Type 2 Model 3 Cable J1772 To 62196
Brand: HEIU
Price: 1 USD

China Ev Charger Type 1 To Type 2 Model 3 Cable J1772 To 62196 wholesale

Brand Name : HEIU

Model Number : T1-T2-32A

Certification : TUV,CE,RoHS

Place of Origin : China

MOQ : 1 PC

Price : negotiable

Payment Terms : T/T, L/C, Western Union

Supply Ability : 1000pcs/Day

Delivery Time : 10-15 days

Packaging Details : Carton Box, Pallet

Cable Material : TPU

Connectors : J1772 to 62196

Weight : 3kg

IP Class : 55

Warrantly : 2 Years

Cable : Straight

Contact Now

Ev Charger Type 1 To Type 2 Model 3 Cable J1772 To 62196

Product Description:

This single-phase charging cable can provide a maximum charging power of 7.4 kW. This charging cable is ideal for all electric cars and plug-in hybrids, especially for charging at public charging stations.

Product Specification:

Vehicle connector type	Type 1 to Type 2 connector - SAE J1772 to 62196-2
Available lengths	3M, 5M, 8M, 10M, 15M
Plug Color	White / Black
Cable Material	TPU
IP class	IP55
Rated current	32 A / 230V - up to 7.4kW, single-phase
Operating voltage	250v
operating temperatur	-30 ℃ to 50 ℃
Grounding	Isolated ground
Mating cycles	10,000
Cable thickness	3*6.0mm² + 2 x 0.5mm²
Certification	TUV, CE

Ev Charger Type 1 To Type 2 Model 3 Cable J1772 To 62196
